12,000 - 15,000 lb Drum

Short Description: Heavy-duty replacement brake drum for 12,000 lb to 15,000 lb trailer axles. Designed for 12-1/4" x 5" electric or hydraulic drum brake assemblies. Features precision-machined friction surface for smooth, consistent stopping power.

Product Features

• Heavy-Duty Capacity: Rated for up to 7,500 lbs per drum (15,000 lbs per axle pair).

• Precision Machined: Smooth interior braking surface ensures full shoe contact, even wear, and reliable stopping under heavy loads.

• Durable Construction: Built with high-strength cast iron to withstand extreme heat and heavy commercial hauling.

• Direct OEM Fit: Direct replacement for Dexter part numbers 9-28-1 and 009-028-01.

Technical Specifications

• Brand / Part Number: Dexter 9-28-1 (009-028-01)

• Brake Size Compatibility: 12-1/4" x 5"

• Axle Capacity: 12,000 lbs – 15,000 lbs

• Bolt Pattern: 8-Hole (7-1/2" Bolt Circle)

• Pilot Hole Diameter: 5-1/4"

• Mounting Hole Size: 5/8"

• Brake Type: Electric or Hydraulic Drum Brakes

Cross-Reference Part Numbers

• Dexter: 9-28-1 / 009-028-01 / 00902801

• Redneck Trailer: 9-28-1 / 9281 / 124600

• Automann: 151.25001

• Nuera: 27-315-2

Note: Listing is for the brake drum only. Hub, bearings, oil seals, and 1/2"-13 x 1-3/4" mounting bolts (Dexter # 007-244-00) are sold separately.
